Stainless Steel Checker Plate

Stainless Steel Checker Plate is a very durable, rust-resistant metal that provides a non-corrosive surface. It can prevent slips and trips by adding traction when wet or oily. It’s also easy to clean with its non-porous property, which makes it an ideal material for industry.

Product Specification and Size

Available Size

Thickness (mm)	Width (mm)	Length
3, 4, 5, 6	1219, 1250, 1500, 1524 Other width according to customer’s request	According to customer’s request
304 No.1

Thickness (mm)	Width (mm)	Length
3	1219, 1250, 1500, 1524 Other width according to customer’s request	According to customer’s request
304 2B

Chemical Composition & Mechanical Property

Chemical Composition (For Reference)

JIS Specification
Spec. JIS G4304	Steel Grade	Ni% Max.	Cr% Max.	C% Max.	Si% Max.	Mn% Max.	P% Max.	S% Max.	Mo% Max.	Ti% Max.	Other
	SUS304	8.0~10.5	18.0~20.0	0.08	1	2	0.045	0.03	–	–	–
	SUS304L	9.0~13.0	18.0~20.0	0.03	1	2	0.045	0.03	–	–	–

Mechanical Property (For Reference)

JIS Specification
Spec. JIS G4304	Steel Grade	N/mm 2 MIN. Tensile Stress	N/mm 2 MIN. Proof Stress	% MIN. Elongation	HRB MAX. Hardness	Bendability: Bending Angle	Bendability: Inside Radius	S% Max.	Mo% Max.	Ti% Max.	Other
	SUS304	520	205	40	90	No Require	–	0.03	–	–	–
	SUS304L	480	175	40	90	No Require	–	0.03	–	–	–
